** CALL FOR PRICING **
ADDED FEATURES
R14 Tires
HST Cruise Kit
KL5521 Loader w/66" QA Heavy Duty Bucket
Grill Guard
FEATURES:
Engine
Model: 3HT-TH4C
Engine Manufacturer: KIOTI
Power: 44.90 hp (33.50 kW)
Displacement: 111.40 cu. in. (1,826 cc)
RPM: 2,600 rpm
Fuel Type: Diesel
Aspiration: Intercular
Fuel Capacity: 12.70 gal (48 L)
Transmission
Transmission: Hydrostatic
Shuttle: Hydrostatic
Travel Speeds Forward: 3 Ranges w/ Infinite Speeds
Travel Speeds Reverse: 3 Ranges w/ Infinite Speeds
Travel Speeds Minimum Speed: 0 mph (0 km/h)
Travel Speeds Maximum Speed: 18.50 mph (29.70 km/h)
Travel Speeds Min Reverse Speed: 0 mph (0 km/h)
Travel Speeds Max Reverse Speed: 20.80 mph (12.90 km/h)
PTO
PTO Type: Independent
PTO Power: 33.40 hp (24.90 kW)
Rear Speed: 540
Mid Speed: 2,000
Drive Train
Brakes: Wet Multi Disc
Clutch: None
Steering: Hydrostatic Power Steering
Hydraulics
Pump: Gear
Pump Capacity: 16.50 gpm (62.40 lpm)
Lift Capacity: 2,716 lb (1,232 kg)
Hitch
Type: Three Point
Category: Category 1
Control Type: Position
Lift Capacity: 1,500 lb (680 kg
Dimensions
Length with Hitch: 125.50 in (3,189 mm)
Width: 62.80 in (1,596 mm)
Wheelbase Length: 71.30 in (1,810 mm)
Ground Clearance: 14.50 in (368 mm)
Front Tread: 49.40 in (1,254 mm)
Rear Tread: 49.30 in (1,251 mm)
Turning Radius: 102.80 ft (2,610 m)
Weight: 3,523 lb (1,598 kg)
Height: 96.80 in (2,458 mm)
