TOTAL MSRP: $95,718
Customer Discount: $22,920
CASH PRICE: $72,798
OR
0% up to 48 mo. OR 2.99% for 84 mo. (OAC) - Pricing & Financing Valid Through 7/31/25
ADDED FEATURES
R14 Tires
Cab
KL1155 Loader
90" QA Bucket
Grill Guard
FEATURES
Dependable Workhorse
Conquer challenging tasks and cruise effortlessly with the power boost feature. This system unlocks an extra 9% in horsepower and torque, ready to tackle demanding PTO applications or propel you down the highway with ease. No need for manual adjustments - simply engage the boost and let the engine unleash its full potential.
Interior Comfort with Premium Features
A spacious five-pillar cab grants panoramic visibility, while the premium air suspension seat cradles you in comfort with adjustable fore/aft, swivel, and heated lower cushion. Need to train a new operator? The standard instructor seat makes it a breeze. The tilt and telescoping steering wheel let you dial in your perfect position.
Powerful Engine
The KIOTI (DD) 4-cylinder diesel engine boasts cutting-edge technology that delivers exceptional power and minimal noise. Its advanced fuel injection system and optimized combustion chamber create a clean, efficient burn that translates to quiet operation and reduced emissions.
Robust Front Axle
An unyielding front axle stands firm against the toughest terrain, while outboard planetary drives seamlessly transfer torque with precision. The limited-slip differential empowers you to conquer muddy fields and traverse loose gravel.
Hydraulic Shuttle
The HX Series has a hydraulic shuttle transmission, where seamless forward-reverse shifts are just a flick of a lever away. Each gear's speed is mirrored in reverse, making repetitive loader work simple.
SPECIFICATIONS:
ENGINE
Model: 4J243TA-TP5B
Engine Manufacturer: KIOTI
Power: 90 hp (67.10 kW)
Displacement: 233.90 cu. in. (3,833 cc)
RPM: 2,200 rpm
Fuel Type: Diesel
Aspiration: Intercular
Fuel Capacity: 47.60 gal (180 L)
TRANSMISSION
Transmission: Manual - Power Shuttle
Shuttle: Power Shuttle
Travel Speeds Forward: 24
Travel Speeds Reverse: 24
Travel Speeds Minimum Speed: 1.15 mph (1.85 km/h)
Travel Speeds Maximum Speed: 23.84 mph (38.36 km/h)
Travel Speeds Min Reverse Speed: 1.14 mph (1.83 km/h)
Travel Speeds Max Reverse Speed: 38.10 mph (23.67 km/h)
POWER TAKE-OFF
PTO Type: Independent
PTO Power: 70 hp (52.20 kW)
Rear PTO Speeds (1st): 540 / 540E / 1000
Mid Speed: N/A
DRIVE TRAIN
Brakes: Wet Multi Disc
Clutch: Wet Multi Disc
Steering: Hydrostatic Power Steering
HYDRAULICS
Pump: Gear
Pump Capacity: 32 gpm (121 lpm)
Lift Capacity: 8,002 lb (4,410 kg)
HITCH
Type: Three Point
Category: Category 2
Control Type: Electronic Control
Life Capacity: 8,002 lb (3,630 kg)
DIMENSIONS
Length with Hitch: 170.78 in (4,338 mm)
Width: 88.58 in (2,250 mm)
Height: 111.93 in (2,843 mm)
Wheelbase: 94.88 in (2,410 mm)
Ground Clearance: 18.94 in (481 mm)
Front Tread: 65.35 in (1,660 mm)
Rear Tread: 70.47 in (1,790 mm)
Turning Radius: 12.69 ft (3.87 m)
Weight: 10,230 lb (4,640.25 kg)
